Ceramic Roller for The Glass Tempering and Processing

Basic Info.

Model NO.	LKT005
Apparent Porosity ( %)	7-11
Sio2(Wt%)	≥ 99.72
Roughness	1.6um
Porosity	10%
Tolerance	+,-0.05mm
Material	Alumina Ceramic, Fused Silica
Purity	99.8%
Grade	Silica Oxide Regular Fine -250
Transport Package	Fumigate Wooden Case with Poly Packaging Inside
Specification	55; 65; 75; 85; 95.25; 105
Trademark	Lekker, Vesuvius, etc
HS Code	7002209000
Production Capacity	10000m Per Month

Product Description

Application:
Fused silica ceramic roller is ideal substitute for graphite rolls and ceramic coating rolls, prevent oxidation and dross build-up, carrying and transmitting glass in glass horizontal tempering furnace and annealing kilns.
Brief Introduction:
Fused silica ceramic roller adopts fined high purity fused silica as raw material and made by foreign advanced grouting molding technique and processing manufacturing line. Molding methods mainly are grouting and gel injection molding, dry pressing and cold isostatic pressing. We can produce big size of fused silica ceramic roller by these methods.There are end caps and end shafts, usually made of metal, tightly connected at both ends of ceramic rolls.In the solar energy industry, the service temperature is about 1150C. In glass industry, the Service temperature: about 900C.
Advantages:
1. Raw material with high purity, excellent chemical and physical properties 2. Good surface smoothness, not easy to scratch glass 3. High density without bubbles 4. Very High Compressive Strength, Flexural Strength & Impact Strength at high temperature. 5. Good wear resistance 6. Small radial beat (run) 7. Very low thermal expansion coefficient 8. Strong thermal shock stability 9. High precision in size 10. No deformation under high temperature 11. Long service life, The reliable axle neck joint technology(anti-loose technology) 12. No pollution to glass 13. High economic efficiency, can reduce the overall cost of belt conveyer, reduce maintenance working hours

Description	Index	Description	Index
Raw Material	Fused Silica	Compression strength	≥ 60(MPa)
Purity	≥99.8%	Transverse strength	≥30(Mpa)
Bulk Density	≥1.98 g/cm3	Radial Beat	≤0.10mm
Apparent Porosity	7-11%	Press Compression	102 Mpa
Expasion Coefficient	≤0.6(x10-6/ºC)	Chemical Composition	SiO2
Surface Roughness	≤1.6um	Shape	Round, hollow, etc
OD Tolerance	±0.05mm	Porosity	10%
T.I.R. (Tolerance in rotation)	≤0.10mm	Packing	Fumigate Wooden Case

Ceramic Roller Popular Sizes:

ID (mm)	Length	OD (mm)	Length
15 - 25	1300mm	66 - 75	3400mm
26 - 30	1400mm	76 - 85	3400mm
31 - 35	1700mm	86 - 90	3400mm
36 - 40	1700mm	91 - 100	3500mm
41 - 45	2200mm	101 - 105	3700mm
46 - 55	3000mm	111 - 120	3900mm
61 - 65	3200mm	121 - 130	4000mm
All the sizes could be made according to customer's drawings
